General Information

Wisenet X powered by Wisenet 5 network IR outdoor vandal dome camera, 2MP, Full HD(1080p) @60fps WDR off or @30fps WDR on, Motorized Vari-Focal Lens 4.3x (2.8~12mm) (119.5°~27.9°), H.265/H.264/MJPEG, WiseStream II compression technology, 150dB WDR, USB port for easy installation, Advanced video analytics and sound classification, High powered IR LEDs range of 164′, True D/N, Dual SD card, Hallway view, HLC, Defog detection with simple focus, DIS , 12VDC/24VAC/PoE, IP67, IK10, NEMA 4X, Built-in -40°F Heater

Technical Information

Recording Formats:	Full HD
HD Recording:	Yes
Night Vision:	Yes
Night Vision Distance:	164.04 ft
Night Vision Type:	Infrared

Display & Graphics

Image Sensor Type:	CMOS
Color Supported:	Monochrome
Color Supported:	Color
Field of View:	H : 119.5° ~ 27.9°/ V : 62.8° ~ 15.7° / D : 142.1° ~ 32.0°
Effective Camera Resolution:	2 Megapixel

Video

Video Formats:	MPEG-4 AVC
Video Formats:	MJPEG
Video Formats:	H.264
Video Formats:	H.265
Maximum Video Resolution:	1920 x 1080
Maximum Frame Rate:	60 fps

Lens

Lens Type:	Varifocal
Minimum Focal Length:	2.80 mm
Maximum Focal Length:	12 mm
Lens Included:	Yes
Lens Mount Type:	Board Mount
Optical Zoom:	4.3x

Exposure

Shortest Shutter Speed:	1/12000 Second
Longest Shutter Speed:	2 Second

Network & Communication

Connectivity Technology:	Wired
Remote Management:	Yes

Storage

Storage Type:

Memory Card

Interfaces/Ports

Network (RJ-45):

Yes

Power Description

Input Voltage:

12 V DC

Physical Characteristics

Mount Type:	Pole Mount
Form Factor:	Bullet
Product Color:	Dark Gray
Height:	14.5″
Width:	3.6″
Diameter:	3.6″
Weight (Approximate):	4.81 lb

Environmental Conditions

Minimum Operating Temperature:	-40°F (-40°C)
Maximum Operating Temperature:	131°F (55°C)
Operating Humidity:	90%

Miscellaneous

Features:	SD Card Local Storage
Features:	Day/Night
Features:	Defog
Features:	Back Light Compensation (BLC)
Features:	Wide Dynamic Range
Features:	Digital Noise Reduction
Features:	Digital Image Stabilization
Features:	White Balance
Features:	Gain Control
Features:	Privacy Masking
Indoor/Outdoor:	Outdoor
NDAA Compliant:	Yes
