Uniden HC84 Guardian Protector Security Kit

Monitor and control your
home security using your smartphone

The Uniden HC84 Guardian Protector Security Kit is a simple and
full-featured base
station plus video camera that is perfect for building your own custom
home security system. It includes a gateway hub with built-in siren
that alerts you when a door or window
is opened, and automatically turns on lamps to ward off intruders.
Plus, there’s an included camera to help record security footage. Even
better, the system can be controlled using your smartphone or tablet,
making it easy to set up and use your system.

• Simple and full-featured base
  station plus video camera that is perfect for building your own custom
  home security system
• Lets you easily monitor and control the security of your
  home through your smartphone
• Gateway hub with built-in siren alerts you when a door or
  window is opened, and automatically turns on lamps to ward off intruders
• System supports up to 24 sensors and up to 4 AppCams and/or
  Guardian
  surveillance systems
• Create
  IFTTT scenarios to personalize your home security

• 1 x Gateway
• 2 x On / Off Switch
• 2 x Window / Door Sensor
• 1 x Passive Infrared Sensor
• 2 x Remote Key Fobs
• 1 x AppCam 24HD
• 2 x Power Adapters
• 1 x Ethernet Cable
• 1 x Quick Start Guide

• Color: White
• Compatibility: Uniden
  AppCam 23, AppCam 24HD, AppCam 25HD, AppCam 26PT and Guardian wireless
  surveillance products G455, G755 and G955

Gateway Hub

• Operating Voltage: DC12V / 1A
• Ethernet: 10 / 100 Mbps
• Sub-1G: 916.8 Mhz

Motion Sensor

• Signal frequency: 916.8 Mhz
• RF range (Line of Sight): Up to 500′
• Maximum detection range: Up to 50′
• Detection angle: 110°
• Battery type: 3 x 1.5V AA
• Battery life: ~ Up to 2 years @ 200
  triggers / day
• Battery powered monitoring: Yes
• Tamper detection: Yes
• Operating temperature: 0°~40° C
• Operating humidity: 10%~80% RH
• Dimensions: 4.3″ x 2.4″ x 2″

Door/Window Sensor

• Signal Frequency: 916.8 Mhz
• RF Range (Line of Sight): Up to
  500′
• Battery Type: 1 X CR2032
• Battery Life: ~ Up to 2 years @
  10 triggers / day
• Battery Powered Monitoring: Yes
• Tamper Detection: Yes
• Operating Temperature: 0°~40°C<
• Operating Humidity: 10%~80% RH
• Dimensions: Large piece: 2.8″ x 1.1″ x
  .5″, Small piece: 2.8″ x .5″ x .5″

Remote Control

• Signal frequency: 916.8 Mhz
• RF
  range (Line of Sight): Up
  to 500′
• Battery
  type: 1
  X CR2032
• Battery
  life: ~
  Up to 2 years @ 10 triggers / day
• Battery
  powered monitoring: Yes
• Tamper
  detection: Yes
• Operating
  temperature: 0°~40°
  C
• Dimensions: 2.4″
  x 1.18″ x .5″

Power Plug Sensor

• Signal Frequency: 916.8 Mhz
• RF Range (Line of Sight): Up
  to
  500′
• Plug Type: USA
• Load Switching Capacity: 1800W
• Battery Powered Monitoring: No
• Operating Temperature: 0°~40°C<
• Operating Humidity: 10%~80% RH
• Dimensions: 3.7″ x 2.2″ x 1.2″

Camera

• Frequency: 2.4GHz
• Signal Transmission: WiFi, Ethernet
• Wireless Connectivity: 802.11 b/g/n
• Security: WEP/WPA/WPA2
• Antenna: Internal
• Camera Performance: HD 720P, 1280 x 720
• Frame Rate: Up to 30fps
• Casing (weather resistance): Indoor
• Image Sensor: 1/4” CMOS
• Night Vision: Up to 25 ‘
• Viewing Angle: H: 75°±3°/V: 45°±3
• # IR LED’s: 5
• Low Light Sensitivity: 1~8 Lux
• SD Card Slot: Up to 32GB
• 4GB: 220 Events
• 8GB: 440 Events
• 16GB: 880 Events
• 32GB: 1,760 Events
• Mount Style: Base
