General Information

Multiple Connectivity Ports
Comes with one HDMI video input port, one HDMI video loop-out port, four HDMI video output ports, eight RJ45 network ports, five 3.5mm IR emitter ports, five 3.5mm IR receiver ports, four S/PDIF ports, one RS-232 terminal block, one DIP switch, five reset buttons, four audio slide switches, one DC power jack (12V/2A) for TX, four DC power jacks (5V/2A) for RXs

Applications

Meeting room
Lecture hall
Educational facilities
Multimedia education
Home theater
Restaurant
Shopping center
Library
Show room

Technical Information

Connectivity Technology:	Wired
Number of Input Devices Supported:	1
Number of Output Devices Supported:	4
Maximum Operating Distance:	229.66 ft

Video

Graphics Modes:	4K
Maximum Video Resolution:	3840 x 2160

Interfaces/Ports

Network (RJ-45):	Yes
HDMI In:	Yes
HDMI Out:	Yes
Number of Network (RJ-45) Ports:	8
Number of HDMI Inputs:	1
Number of HDMI Outputs:	5

Media & Performance

Media Type Supported:	Twisted Pair
Twisted Pair Cable Standard:	Category 7

Power Description

Frequency:	50 Hz
Frequency:	60 Hz

Physical Characteristics

Product Color:	Black
Transmitter Height:	0.91″
Transmitter Width:	10.43″
Transmitter Depth:	4.09″
Receiver Height:	0.79″
Receiver Width:	4.15″
Receiver Depth:	4.04″
Transmitter Weight (Approximate):	1.46 lb
Receiver Weight (Approximate):	8.64 oz

Miscellaneous

Package Contents:	1 x Transmitter 4 x Receiver 5 x Power Adapter 1 x IR Blaster extension cable 4 x IR Receiver extension cable Terminal block Mounting kit User Manual
Country of Origin:	China
Environmentally Friendly:	Yes
