General Information

The Wyr-Grid® Support Bracket is used to support the 24.0″ (609.6 mm) wide Wyr-Grid® Pathway to standard 3.0″ (76.2 mm) or 6.0″ (152.4 mm) EIA channel racks. It is black powder coated and is 3.4″ (86.4 mm) high, 28.5″ (723.9 mm) long, and 7.6″ (193.0 mm) wide. The bracket can be installed as a parallel or perpendicular support for the Wyr-Grid® Pathway and attaches directly to Panduit channel racks. It comes in standard packages of one.

Product Information

Device Supported:

Cable Pathway

Physical Characteristics

Product Color:	Black
Finishing:	Powder Coated
Product Material:	Steel
Height:	3.4″
Width:	7.6″
Length:	28.5″

Miscellaneous

Package Contents:	Wyr-Grid Mounting Bracket 1 x Wyr-Grid Rack Mount Bracket Base Assembly 2 x 1/4-20 X .75″ Round Head Square Neck Bolt 2 x 1/4″ SAE Flat Washer 2 x 1/4″ Helical Spring Lockwasher 2 x 1/4-20 Hex Nut
Country of Origin:	China
Environmentally Friendly:	Yes
