General Information

The IMC-370 series offers the most compact media converters. They can extend the 10, 100 and 1000Mbps twisted-pair network segments up to 80km over fiber technology. Supporting both 10/100/1000Mbps auto negotiation on the copper port and 1000Mbps full-duplex on the fiber port, the IMC-370 series serves as a media and data rate converter.

The IMC-370I-SFP supports Link Fault Pass Through (LFPT) functionality which can be enabled/disabled by a DIP switch on the unit. This useful diagnostic feature assists the network administrator in indicating a fault condition on a given segment between the interfaces.

The IMC-370I supports plug-n-play functionality, auto negotiation, and AutoCross operation. It can be powered by AC/DC power, dual USB cable, or via installation in a centrally-powered media converter chassis.

Interfaces/Ports

Total Number of Ports:	2
Network (RJ-45):	Yes
Number of Network (RJ-45) Ports:	1
Number of SC Ports:	1
SC Port Type:	Duplex

Media & Performance

Media Type Supported:	Optical Fiber
Media Type Supported:	Twisted Pair
Fiber Mode Supported:	Single-mode
Fiber Optic Wavelength:	1310 nm
Maximum Distance Supported:	6.21 Mile

Network & Communication

Ethernet Technology:	Gigabit Ethernet
Network Technology:	1000Base-TX
Network Technology:	1000Base-LX

Power Description

Power Source:	AC
Frequency:	60 Hz
Frequency:	50 Hz

Physical Characteristics

Form Factor:	Wall Mountable
Form Factor:	Rail-mountable
Height:	0.8″
Width:	1.8″
Depth:	3.4″
Weight (Approximate):	11.18 oz

Miscellaneous

Package Contents:	10/100/1000Mbps Miniature Media Converter Power Adapter
Application/Usage:	Network
Certifications & Standards:	CE FCC Class A UL/cUL
Environmentally Friendly:	Yes
Environmental Compliance:	Restriction of Hazardous Substances (RoHS)
